50ft trailer mounted
boom lift
Trailer Mounted Boom Lifts
The 17 meter is a highly maneuverable trailer-mounted boom lift, ideal for achieving significant reach and versatility in tight spaces. It features a robust rigid chassis and an automatic 10.5º leveling system that allows for quick setup in under 40 seconds.
Designed for easy transport, it can be towed by vehicles with a 50 mm ball hitch, while providing 359˚ non-continuous turntable rotation for flexible positioning. With a maximum working height of 17.09 meters, a horizontal reach of 8.89 meters, and a platform capacity of 200 kg, it ensures safe operation and efficiency across various applications, stowing easily at a height of 2.00 meters and weighing 2,200 kg.
Overview:
- Rigid chassis and automatic 10.5º levelling system allows the machine to be set-up in less than 40 seconds
- Easy to transport. Can be towed behind vehicles with a 50 mm ball coupler
- 359˚ non-continuous turntable rotation for versatile positioning
- Extension boom with self-levelling platform for safe, precise setup
- 200 kg capacity across the range of motion
- 1.25 m (4ft) jib with 135º working range and standard platform rotation for easy positioning
A high-risk work licence is required to operate a boom-type elevating work platform (EWP) that is 11 meters or higher
Specifications
| Max Working Height | 17.09 m |
| Horizontal Reach | 8.89 m |
| Platform Capacity | 200 kg |
| Up and Over Clearance | 6.71 m |
| Length- stowed | 7.16 m |
| Stowed Height | 2.00 m |
| Outrigger footprint | 4.4 m |
| Weight | 2,200 kg |
